Description
Fill-Rite FR319VBP 35 GPM 115/230V AC 50/60 Hz Super High Flow Pump provides long life. Explosion-proof UL listed dual voltage 3/4 HP motor (115 and 230 VAC). Motor has sealed bearings, heavy-duty switch, thermal overload protection, built-in junction box, cast iron pump housing with iron rotor and carbon vanes. Also includes check valve, pressure relief valve, strainer assembly, automatic bypass valve, 2 in. NPT threaded bung for tank openings. 18 ft. hose, 1 in. automatic ultra high flow nozzle. Pump has a 2-Year Warranty.
Feature
- Flowrate Range: 0-35 GPM
- Inlet / Outlet Thread Size (in.): 1.25 / 1
- Motor Power: 3/4 HP motor
- Current Range: 9.8/11.4 4.9/5.7
- Dry Vacuum (in. Hg): 14
- Max Discharge Pressure: 26
- Discharge Head (ft.): 60
- Max Operating Pressure (PSI): 26
- Strainer Mesh Size (micron): 40x 40 x .008”
- Accuracy (+/- %): 1.25
- Repeatability (+/- %): 0.38
- Display Digits: 4
- 18 ft. lift capacity
- Thermally protected motor
- 30-minute duty cycle
- Ultra hi-flow nozzle
- 1 in. x 18 ft. hose
- 1'' Ultra High Flow Automatic Nozzle (Truck Stop Spout and Red Cover)
- 900CDP Digital Meter with 10:1 Pulse Output
- Intrinsically Safe Barrier
- Diesel Only
Application
